Core X-ray microscope OBL-12

The OBL series is distinguished by its advanced infinity optics, making it ideal for demanding users in all illumination applications. The microscope's robust and ergonomic base ensures both safety and comfort during prolonged use.

Powerful Illumination: Equipped with a powerful, continuously dimmable 3W LED illumination, the OBL series provides bright and consistent illumination for precise observations.
Advanced Condenser: The fixed pre-centred and focusable 1.25-Abbe condenser with aperture and light field diaphragm provides simplified Köhler illumination with no adjustable centre, enhancing user-friendliness.
Efficient specimen handling: the large mechanical cross-table and object holder can hold up to two specimens simultaneously. The coaxial coarse and fine focus control on both sides of the microscope allows quick and easy focusing.
Comprehensive Accessories: The OBL series offers a wide choice of accessories, such as eyepieces, objectives and colour filters. In addition, options are available for a dark field condenser, a simple polarisation unit, several phase contrast sets and an HBO and LED fluorescence unit.

Application areas:
Haematology, Urology, gynaecology, dermatology, pathology, microbiology and parasitologi, immunology, Purification plants, oncology, entomology, Veterinarians, water analysis, breweries.

Technical specifications:
Optical system: Infinity
Eyepieces: magnification 10x ø20 mm
Lens quality: Infinity E-Plan
Screw-in spots: 4
Illumination type: LED
Illumination intensity: 3W
Field of view: 0.2 - 5 mm
Focus mechanism: Coarse/fine focus coaxial
Dimensions OBL 127: 395 x 200 x 380 mm
Dimensions OBL 137: 394 x 185 x 377 mm
